아두이노 DB와 휴대폰 바코드 연동하여 TFT LCD에 출력하기

동영상 확인하기





#define   _TFTLCD_      myLcd              // TFT LCD 이름 정의
#define _INDEX_TYPE_2_                     // 인덱스방법 2로 사용시
                                           // 방법 1로 사용시 주석처리 하면 됨
#include  "D:\\Program Files (x86)\\Arduino\\myHeader\\HanGul_TFT.H"


HanGul_TFT  ht;     // 한글출력 클래스

#define dbFileName  "BarCode.txt"
File    dbFile;

struct Record  // 레코드 구조체
{
     String   barCode;
     String   productName;
};

String readLine()
{
  char buff[50];
  int idx=0;

  while(true)
  {
     byte b,b2;

         b=dbFile.read();
        if( b == 0x0d )
        {
            b2=  dbFile.read();
            if( b2 == 0x0a )
            {
               buff[idx]= 0;
               return( String( buff ) );
            }
            buff[idx++] = b;
            buff[idx++] = b2;
        }
        else buff[idx++] =b;
  }
}

void addRecord( String _barCode, String _productName )
{
    dbFile = SD.open(dbFileName,FILE_WRITE);
    dbFile.println( _barCode );
    dbFile.println( _productName );
    dbFile.close();

}

Record findRecord( String  _barCode)
{
  Record rec;
  dbFile = SD.open(dbFileName);
  while( dbFile.available() )
  {
      if( _barCode == readLine() )
        {
          rec.barCode=_barCode;
          rec.productName=readLine();
          dbFile.close();
          return( rec );
        }
      readLine();
   }
  dbFile.close();
  rec.barCode="-1";
  return( rec);
} // func



bool togColor =true;

void setup()
{

  ht.start();       // 한글출력 클래스 시작

  myLcd.InitLCD();
  myLcd.setRotation(3);   //3 가로 480x320  //2 세로   320x480
  myLcd.clrScr();
  myLcd.fillScreen(cGreen);
  ht.color(cWhite,cBlue);
  ht.print(F("휴대폰 바코드 연동 DB "),0,0,2,3);
  ht.under(cWhite);
  ht.color(cWhite,cGreen);
  ht.print(F("메세지:"),5,100,2);
  ht.print(F("바코드:"),5,170,2);
  ht.print(F("상품명:"),5,220,2);
  ht.color(cYellow);
  ht.print(F("블루투스 연결 대기중"),130,100,2);
  Serial.begin(9600);
  while( !Serial.available() )
  {
    if( togColor ) ht.fill();
    else ht.print(F("블루투스 연결 대기중"),130,100,2);
    togColor = ! togColor;
    delay(700);
  }
  ht.print(F("블루투스 연결됨       "),130,100,2);
}

String temp;

void loop()
{
 String msg,cmd;
 Record rec;

 if(Serial.available() )
 {
  msg=Serial.readString();
  cmd=msg.substring(0,1);
  msg=msg.substring(1);

  if( cmd[0]=='B' )
  {
       rec=findRecord(msg);
       if( rec.barCode =="-1" )
       {
            ht.print(F("등록이 필요한 바코드          "),130,100,2);
            temp=msg;
            ht.print(msg+"                ",130,178);
            ht.print("                         ",130,220,2);
            Serial.print("-1");
        }
        else
        {
            ht.print(F("검색 되었습니다.              "),130,100,2);
            ht.print(rec.barCode+"               ",130,178);
            ht.print(rec.productName+"           ",130,220,2);
            Serial.print(rec.productName);
        }
  } else if( cmd[0] =='A')
  {
         addRecord(temp,msg);
         ht.print(F("등록 되었습니다.     "),130,100,2);
         ht.print(temp+"              ",130,178);
         ht.print(msg+"             ",130,220,2);
         Serial.print("1");
  }


 }


}//loop
